RLT-2401T 2.45GHZ ACTIVE RFID TAGS
monitoring, anti-counterfeiting system and production process control.
Product introduction
This 2.4GHz active label RLT2401T, adopts ultra-low power consumption design, and the label has a longer service life; the effective visual recognition distance is more than 200 meters; which structure is simple and compact, and with light weight, it can be pasted or fixed with screws; with frequency hopping mode, strong anti-collision and anti-interference ability.Can be widely used in logistics tracking, commodity inventory, cargo sorting, vehicle management, asset management, medical system, cold chain management, temperature monitoring, power monitoring, anti-counterfeiting system and production process control.
Product Features
l Ultra-low power consumption design, longer service life；
l Effective visual recognition distance of more than 200 meters；
l Frequency hopping operating mode, stronger anti-collision and anti-interference capabilities；
l Ultrasonic packaging process, waterproof rating up to IP54;
l Compact and lightweight, with various installation methods, can be pasted or fixed with screws
Specifications
General parameters | |
Product Dimensions | 38*38*14mm |
Weight | Net 15g |
Operating Temperature | -20℃～+60℃ |
Storage Temperature | -40℃～+80℃ |
Humidity | 5％～95％(non-condensing) |
Battery parameters | CR2450 |
Battery Life | 1-5Years (Non-replaceable) |
Performance Indexes | |
Operating Frequency | 2.4GHz～2.4835GHz |
Current | <1μA/Static,<20mA(Transmission) |
Signal Speed | 1Mbit/s |
Transmission Power | 0-7dBm |
IP Rate | IP54 |
